Parallel Swing Away Hub – Heavy Duty
Price
$97.47 Inc.GST
Brand: Couplemate™
Uses quality Japanese bearings from NSK.
Shipping
Parallel Swing Away Hub
The Couplemate™Parallel Swing Away Hub Swing Away Spare Wheel hub is a swing-away flangeless hub with bearing cones.
Heavy-duty swingaway can carry dual spare wheels, jerry cans, or large 4WD accessories.
Product Specifications
Couplemate™ manufactures Swing Away Hubs from K1040, a high-grade Australian steel. This is the same grade of steel used for stub axles, as seen in the 4WD Swing Away Rear Kits, as this ensures a sturdy and quality product.
The Flangeless Hub is manufactured to suit the following bearing profiles:
The kits contain NSK-branded inner and outer bearing cones, our Australian-made dust caps, and seals.
Use tapered roller bearings on trailer and caravan axles as they handle a variety of awkward weights (such as spare wheels, jerry cans, trailer lifts, etc.).
Replace the 4WD swing-away spare wheel carrier if the weight exceeds the bearing limitations. This results in assembly collapse, and if such, replace it with the non-bearing type carrier.
Couplemate™ recommends either the 45mm Slimline or 45mm Parallel model due to the added load caused by the fulcrum effect on the rear bar.
Image 1. The circled area is an example of a swingaway used as a Spare Wheel Carrier.
Installation Note
Bearing cups are already machined into the hub. Do not insert new cups into the hub if you are replacing the bearings for any reason.
LM or Holden Bearings (no spindle)
- Inner ID 31.75mm, OD 59.10mm
- Outer ID 19.05mm, OD 45.20mm
- Seal ID 37.5mm, OD 59.10m
- Grease Cap 45.20mm
SL or Slimline / Ford Bearing Kit (no spindle).
- Inner ID 35.00mm, OD 59.10mm
- Outer ID 22.00mm, OD 45.20mm
- Seal ID 43.9mm, OD 59.10mm
- Grease Cap 45.20mm
Parallel Hub only plus Bearing Kit (no spindle).
- Inner ID 35.00mm, OD 59.10mm
- Outer ID 35.00mm, OD 59.10mm
- Seal ID 43.9mm, OD 59.10mm
- Grease Cap 63.00mm
Purchase more spare wheel carriers here
Additional information
| Weight | 1.5 kg |
|---|---|
| Dimensions | 15 × 6 × 6 cm |
